How to Transfer the Display IC Chip on an AQ7 Screen for iPhone 14?

Mobile repair professionals often encounter various issues with iPhone screens, and one common problem is a malfunctioning Display IC (Integrated Circuit) chip. If you're working with an AQ7 screen for an iPhone 14 and need to replace the Display IC chip, this guide will walk you through the process step by step. It's important to remember that this procedure requires expertise and precision, so make sure you have the necessary tools and skills before attempting this repair.

Tools and Materials:

Before you start, gather the following tools and materials:

1. iPhone 14 AQ7 screen with a faulty Display IC chip

2. Appropriate replacement Display IC chip

3. Soldering station with a fine-tip soldering iron

4. Soldering wire or solder paste

5. Flux for soldering

6. Tweezers

7. Heat-resistant tape

8. ESD (Electrostatic Discharge) protection equipment

9. Heat gun or hot air rework station

10. A steady and well-lit workbench

11. Safety goggles and gloves

Step-by-Step Guide:

1. Safety First: Always prioritize safety by wearing appropriate protective gear, including safety goggles and gloves. Ensure that your workspace is well-ventilated.

2. ESD Protection: Use ESD protection measures to prevent static electricity from damaging sensitive components. Ground yourself and your workspace to eliminate any static charge.

3. Screen Removal: Carefully disassemble the iPhone 14 to access the AQ7 screen. Remove any screws, connectors, and components that block access to the screen.

4. Heat Gun Preheating: Preheat your heat gun or hot air rework station to an appropriate temperature, which may vary depending on the specific chip and equipment you are using. Typically, temperatures between 250-350°C (482-662°F) are suitable.

5. Chip Removal: Use the preheated heat gun to warm the area around the faulty Display IC chip. Apply heat evenly to avoid overheating or damaging surrounding components. Once the solder has melted, gently lift the chip using tweezers.

6. Cleaning: Clean the area where the old chip was removed using solder wick or a soldering iron to ensure there is no excess solder residue.

7. Flux Application: Apply flux to the solder pads where the new Display IC chip will be placed. This will help with the soldering process.

8. Chip Placement: Carefully position the replacement Display IC chip on the solder pads, ensuring that the orientation is correct. Use tweezers to hold the chip in place.

9. Soldering: Use a fine-tip soldering iron to carefully solder the new chip to the solder pads. Ensure that the soldering is precise and that there are no solder bridges or cold joints.

10. Testing: Before reassembling the iPhone, test the screen to ensure that the replacement Display IC chip is functioning correctly. Connect the screen to the device and power it on.

11. Reassembly: Once you've verified that the replacement chip is working properly, reassemble the iPhone 14, making sure all components are securely connected.

12. Quality Control: Conduct a final inspection to ensure that the repaired screen is fully functional and free from defects.

Replacing the Display IC chip on an AQ7 screen for an iPhone 14 is a delicate and intricate repair job that requires the right tools, skills, and experience. If you're not confident in your abilities, it's advisable to seek the assistance of a professional technician or repair service. Remember that safety and precision are paramount in this process, and always exercise caution when working with sensitive electronic parts. Mobilesentrix is the leading iPhone OLED Screen Wholesale supplier in the USA.

Ultimate guide to choosing the best Cell Phone Repair Tools

Running a business is about creating your lasting competitive advantage. Still, in the cell phone repair business, where many owners are fighting to differentiate themselves from their competitors, your store can stand out.

To make things easier for you, we've compiled a list of the best cell phone Repair Tools you can stock in your store. But, before we move on, let’s understand the importance of Repair Tools &accessories.



Why is it important to buy cell phone Repair Tools?

Using Cell Phone Repairing Tools you can easily repair any smartphone device. If you are in the market for a kit, the General Tools 660 Smart Phone Repair Kit is a wise pick. This smart phone repair kit includes tools that are capable of aiding in the repair of a variety of devices. Many new tools are launching every day, but which is more useful that is very important. So, it is imperative to use the best phone fixing tools. Use High quality Repair Tools because they are more comfortable.

5 New Cell Phone Repair Tools

DT-01 Pen Type Mini Multimeter 3 in 1

the Relife DT-01 Smart Pen Type Mini Multimeter is a Precision Instrument Designed for working with compact PCB Like Motherboards, Logic Boards etc.

TDT-01 Pen Type Mini Multimeter Features

• AC and DC Voltage
• Resistance
• Diode
• Capacitance
• On-off Beep
• Black Display
• Frequency
• Temperature
• Data Retention
• Automatic Shut-Down

https://www.mobilesentrix.com/dt-01-pen-type-mini-multimeter



Screwdrivers Wolve - 880

Precision 3D Screwdriver High quality latex rubber finger tips are universal Call Phone PCB Repair Phone tool. Generally used to spread silicone Grease Evenly on all kinds of electronic circuit boards for soldering repair. The finger Guard is very convenient tool which will offer good service for professional maintenance of your Cell phone.

Wolve Tools - https://www.mobilesentrix.com/brands/wolve

Sunshine anti-Static Opening Tools SS-040

·         It Can be used to Separate the Screen from the Cell Phone, Remove the Cable from the cell phone, Remove the battery from the cell phone, etc.

• Four Corner curved design, meet the needs of different disassembly situations.
• Thick and thin edge: as thin as 0.50mm, easy to open.
• Anti-Slip fingerprint Design, easy to grip at your fingertips.
• Made of imported material, stronger than other opening tools.
• It is Durable and used Polycarbon Plastic.



Qianli / Mega - IDEA Preheater

This Qianli MEGA-IDEA Platform is a standalone pre heat / Soldering / De-Soldering Platform that is designed to work solely with logic Boards on iPhone 11, iPhone 11 Pro and iPhone 11 Pro Max.

Why use it?

This Soldering Platform is used for Reflowing Logic Boards, PRE-Heating Logic Boards, also used for Layered Logic Board Separation. Removing Gum from IC Chip, Removing and Replacing IC Chips.

https://www.mobilesentrix.com/dt-01-pen-type-mini-multimeter

Best ways to buy cell phone Repair Tools & Accessories

Now that you know which phone accessories to buy for your store, the question is, how and where to buy them.

Mobilesentrix is the leading cell phone parts andaccessories supplier in the US. You can buy all the Mobile Phone Parts wholesale from Mobilesentrix. This will ensure your profit margin for each accessory is as high as possible. We offer 2000+ Cell Phone Repair Tools at wholesale price. Tools are important for any Repair Shop. The best part about buying accessories from Mobilesentrix is that you get a lifetime warranty on all products. When you offer your customers a lifetime warranty, they will be more likely to buy from you. Win-win for everyone!

Why choose MobileSentrix over other wireless repair parts Distributors?

Mobilesentrix is the Largest E-commerce Distributor of Wireless Repair Parts. We are the industry leader in Parts Distribution, and we innovate by controlling the quality above industry standards and have aggressive pricing. We are providing Cell Phone Parts, Macbook Replacement Parts, Game Console Parts and Pre-owned Devices at wholesale prices. We Supply Small to Large Businesses in the USA and all around the world. There is no compromise with the quality of the product, all parts are quality tested before shipping. Our aim is to provide the best quality parts at the best price to our customers and fulfill their requirements.

Our Services:

SWAP Program: We take in good Displays which is broken glass and get it "Swapped" for a new one for a fraction of the price.

LCD Buyback Program: 24–48 Hour Testing Time Period. Video Record Results. High Payout.

RMA Program: A return merchandise authorization (RMA) is a part of the process of the product warranty period.

Our Products

      1. Casper Screen Protector

There are many types of Tempered Glass available online, but not all are safe and protective. MobileSentrix provides Casper Screen Protector for iPhone’s, iPad’s, Google Pixel and Samsung Device. This Casper Tempered Glass is five times stronger than ordinary Cell Phone Tempered Glass.

The perfect shock resistant, anti-glare feature, waterproof, oil contamination, perfectly design for your device. This Casper Tempered Glass has 95% transparency and it comes with Oleophobic coating.

2.       AMPSentrix

1. AMPSentrix Batteries

• Our AMPSentrix Line is the industry game changer. These batteries are certified and the quality is just fantastic. If you have no tried our Ampsentrix batteries, you are definitely missing out.

1. AMPSentrix Plus Batteries

• AmpSentrix Plus batteries are same size batteries with more capacity. This is possible due to newer core technologies. Manufactured under the same rigorous standards as per our AmpSentrix Line.

1. AMPSentrix Power

• AMPSentrix Power is Power Bank for iPhones. Power bank with high capacity AMPSentrix Battery inside for specific replacement models. Easily fit into your carry bag and charge your mobile device anytime and anywhere.



AMPSentrix Certifications

PSE COMPLIANT - Power Sourcing Equipment. A power over Ethernet (PoE) device that is a source of power, such as a PoE Ethernet switch. Contrast with "powered device" (PD), which uses the power, such as a network camera or IP phone. See POE.

RoHs - Restriction of Hazardous Substances. Is the acronym for Restriction of Hazardous Substances. RoHS, also known as Directive 2002/95/EC, originated in the European Union and restricts the use of specific hazardous materials found in electrical and electronic products.

MSDS - Material Safety Data Sheet (MSDS) is a document that contains information on the potential health effects of exposure to chemicals, or other potentially dangerous substances, and on safe working procedures when handling chemical products.

UN 38.3 PASSED - UN Transportation Testing. UN Transportation Testing (UN DOT 38.3) for Lithium Batteries. Intertek provides testing to UN/DOT 38.3 requirements, to ensure the safety of lithium batteries during shipping. Nearly all lithium batteries are required to pass section 38.3 of the UN Manual of Tests and Criteria (UN Transportation Testing).

AMPSentrix is the place to buy the Best Batteries for iPhone in the USA. All iPhone Batteries comes with Zero – Cycle count, OEM TI Gas Gauge Chip, and Pre-installed Battery Adhesive.



3.      Our Product’s New Quality Standards

Genuine OEM

•  We are an Authorized Distributor of LG cell phone parts. All Genuine OEM parts are replacement parts that come from a device OEM.

Premium

•  We use the premium badge in products with little to none alterations done to the replacement part or its components, maintaining the original structure and properties.

Refurbished

• A refurbished part means it has been reconditioned, repaired, rehabilitated, or similar to restore the replacement part to its original purpose.

XO | Technology

• XO7 Technology is also known as Aftermarket Pro. Aftermarket Pro means our engineering team is fully involved in the product development, and our procurement team is engaged in the material sourcing of a replacement part.

Aftermarket Plus

•  Aftermarket Plus is the best third-party manufactured replacement part sourced from the factories. Our average vendor can expect a rejection rate of 35% of goods. While you might see a brand such as ZY on our website, we guarantee the overall quality will be better than any other vendor due to our rigorous testing.

OEM Pull

• Pull or OEM Pull is any replacement part that was pulled off an OEM device. Many times, a device can be worthless compared to the worth when disassembled and sold for parts.

Read more Details: https://blog.mobilesentrix.com/mobilesentrix-new-quality-standards-for-cell-phone-lcd-screens/

About Mobilesentrix

Mobilesentrix endeavors to provide the highest quality product at the best value to customers. Here, you can Buy Wholesale Cell Phone Replacement Parts, MacBook Parts, Game Console Parts, and Mobile Phone Repair Tool in one place at an affordable price. Mobilesentrix is a dedicated supplier of Samsung Cell Phone Replacement Parts, Mobile Phone Parts Wholesale, Cellular Phone Parts, Cell Phone Accessories, Samsung Phone Tempered Glass, Factory direct prices for maximum savings. We are always trying to provide the Latest and upgraded Replacement Parts to our valuable customers, Enjoy our Online shopping with our professional sales system and excellent customer service.

Enable GingerCannot connect to Ginger Check your internet connection
or reload the browserDisable in this text fieldEditEdit in GingerEdit in Ginger×

How to choose best Mobile Phone Parts and Accessories Distributor

 Now a day, Mobile Phone is a part of our life, Smartphone has changed our Lifestyle without the mobile phone we can't image our lifestyle. You can hardly name a person who does not use a cell phone. Unfortunately, if your Cell Phone got Damaged then need to buy New Mobile Phone Replacement Parts for DIY's or visit the nearest repair shop.

Many People looking best quality Mobile Phone Parts online and some of people are looking for New and trusted Accessories distributor near you. With so many parts distributors for smartphones available locally and online, how do you choose the best one to fix your phone? Here are tips to help you find the best provider, whether the issue with your phone is a cracked screen, dead battery, or something else.

Need to Research the Distributor's Background

First, You can look up anything online in the Search engine, and Read customer reviews of wholesale Samsung Mobile Phone Parts Distributor. Make sure you are buying Mobile Phone Replacement Parts from a reputable provider who delivers on time and Payment methods.

Likewise, check how long the organization has been doing business. If they have five years’ experience, then chances are they are doing right and making a name for themselves in the Cell Phone Repair Industry since 2015 and has several favorable customer testimonials, and many repeat customers.

Select an All-in-One Wholesale Mobile Phone Replacement Parts Distributor.

Another tip for making a smart purchase decision when it comes to buying Mobile Phone Replacement Parts is to choose wholesale cell phone parts distributors that offer a one-stop-shop.

Rather than making separate Purchase online for Replacement Parts and Tools, you can do it all in one convenient place at Mobilesentrix. Simplify the buying process and also enjoy delivery of everything you need for the repair project all at once, with fast shipping.

Mobilesentrix matches the Cell Phone Replacement Parts with the model of Phone, making it easier for you to find the correct parts, such as the size of the screen, for your iPhone or another type of mobile phone. also, the correct tools to use are suggested for you, saving you time and energy. Just order then at the same as the replacement parts from wholesale cell phone parts distributor to streamline the buying process!Enable GingerCannot connect to Ginger Check your internet connection
or reload the browserDisable in this text fieldEditEdit in GingerEdit in Ginger×

Tips to fix Cell Phone Charging Problem

In 2018, nearly 240 million people of us are using a Smartphone. People are using more and more Cell phones with the passage of time. You can easily manage your small business by using a Smartphone or tablet. These wireless electronic gadgets are used in so big quantity. They come up with many types of issues like mobile charging issue, software related issues or hardware component that gets damaged. For all of these faults, Phone repairing is the place. There are many online mobile repairing courses and tutorial classes. Here we are sharing some DIY tips to repair your Mobile Phone in just simple steps.

Let's discussion of certain issues that we face while using a phone. A most common problem in Mobile is the charging issue. This basic issue that everyone facing while using Cell Phone. Charging a phone has always been a task. Every time, it is less charged or overcharged in comparison to the usage. Although we come across many issues like software problems, Headphone jack issues, volume control, touch pads, adapter issue, faulty USB port etc. and many others but Mobile charging seems the most common concern in this area.

However, major Cell Phone Charging Port damaged issues can be solved by mobile repair technicians. MobileSentrix shares some common techniques which is really helpful to resolve you’re charging problem. Examine how you can learn how to fix mobile repairing issues:

•    Turn-off your mobile and restart

This is the simplest method to fix the charging problem. This is the first trick when your cell phone does not charge. Simply switch off your phone and after 1 or 2 minute Switch on your Cell Phone. By doing this, you will kill the unwanted Application in the background. This will also clear unwanted data running. Clearing off the data will make the phone easy to work.

•    Check the charging cable properly

In many cases, we do not check the charging cable of our Cell Phones and charging cable has the issue in charging a mobile phone. The cable may be curled, jingled, distorted or may not be working in a proper state in order to charge the mobile properly. At least one time you must try inserting a new charging cable, it may charge your phone. If not, you should try second tips to fix your charging issue.

•    Clean your Mobile Charging Port

This is the best technique to fix mobile Charging issue. When we are using our Mobile phone normally, sometimes the dust in the charging port is fill up so that your mobile phone cannot charge properly. You can use the Phone brush to clean your cell phone charging port. After clean charging port, you should try to charge your mobile phone. If your phone is charged then the happy moment for you, or if not charged then you should try another way.

•    Change Damaged Charging Port

This is a little hard repairing way of mobile. You need to use some Mobile repair tools.

Step-1, use Screwdriver to remove the bottom two-screws,

Step-2, Place your Suction Cup on Phone Screen and gently pry up from the bottom. Need to be careful because the entire screen is attached by several cables, so remove those cables and free your LCD Screen.

Step-3, now you can see holding bracket on charging port, you need to remove holding bracket by using a screwdriver. After Remove Bracket, eject damaged charging port and replace with the new and working Charging port.

Step-4, After Attach new charging port, check your mobile phone charged or not? If yes then you can fix your new charging port. Now fix Holding Bracket and Re-attach LCD Screen.

About MobileSentrix

Mobilesentrix is leading Cell Phone Repair Parts and CellPhone Replacement Parts Supplier in the USA. We supply Accessories for all Mobile Phones like iPhone, Samsung, HTC, LG, Oneplus, Microsurface and many more. We are providing Mobile Phone Parts, Wholesale Phone Replacement Parts, Smartphone parts, Samsung charging Port, iPhone Charging Port at the best price. Customer query is our first priority. It’s our honor we have opportunity top service you.
